Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm

گواهی
چین TYSIM PILING EQUIPMENT CO., LTD گواهینامه ها
چین TYSIM PILING EQUIPMENT CO., LTD گواهینامه ها
من گفتم رئیس من، رافائل، که محصول شما را بسیار دوست داشت، امیدوار است تا همکاری های بیشتر و بیشتر کسب و کار را به شما نشان دهد، همانطور که به شما می گویم که رئیس من با محصول بسیار راضی است.

—— خانم بیت لحم

ما تحت تاثیر کیفیت و خدمات مطلوب قرار می گیریم. ما به دنبال یک کسب و کار خوب با شرکت شما هستیم.

—— آقای Win Hlaing

چت IM آنلاین در حال حاضر

Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm

Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm
Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm

تصویر بزرگ :  Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm

جزئیات محصول:
محل منبع: جیانگ سو، چین
نام تجاری: Tysim
گواهی: CE/ISO900A
شماره مدل: KP315
پرداخت:
مقدار حداقل تعداد سفارش: 1 مجموعه
قیمت: Negotiation
جزئیات بسته بندی: بسته بندی برهنه و حمل و نقل کلی از طریق دریا با کشتی رول روی رول آف. یک ظرف قفسه تخت.
زمان تحویل: 45 روز کاری پس از دریافت پرداخت شما
شرایط پرداخت: L/C، T/T
قابلیت ارائه: 30 ست در ماه
توضیحات محصول جزئیات
قطر شمع: 300 ~ 1050 میلی متر Max. حداکثر cylinder stroke حرکت سیلندر: 135 میلی متر

Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm 0



Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm 1

Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm 2

Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm 3



Technical specification 13 modules combination
KP315
18 modules combination
KP380
Pile diameter 300~1050 mm 600~1800 mm
Max. rod pressure 280 kN 600 kN
Max. cylinder stroke 135 mm 150 mm
Max. crowd pressure 34.3 MPa 34.3 MPa
Max. single cylinder flow 20 L/min 30 L/min
Quantity/8h 60/8 h 48/8 h
Max. single cutting height ≤300 mm ≤300 mm
Excavator capacity 20 35
Single module weight 100 kg 230 kg
Single module size 520*444*316 mm 696*566*350 mm
Operating size Φ2098*4000 mm Φ3316*4840 mm
Overall weight 1.7 t 4.5 t



Better tool for construction Hydraulic Round Pile Breaker Kp315 Pile diameter 300~1050 mm Max. cylinder stroke135 mm 4



Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
